WireCheck
Wire Fault Diagnosis Tool
WireCheck is an extremely sensitive Time Domain Reflectometer designed specifically for detecting chafing and other soft faults in cables.
More about WireCheck
With the ability to detect chafes at sub-inch accuracy to greater than 200ft*, WireCheck Time Domain Reflectometer simplifies difficult troubleshooting tasks on aircraft and other systems with limited cable access and/or where faults are intermittent. Above all, WireCheck comes with common cable attachments. Included MATLAB calibration functions dramatically increase sensitivity and dynamic range during post-processing.
Simply connect the instrument leads to the wire-under-test and ground, and start a scan. Likewise, WireCheck injects low-level 600mV pulses with extremely fast 50psec rise/fall times into the cable at a rate of ten million per second. An 18GHz track-and-hold plus 200MHz 12-bit ADC act as a sampling scope to generate a trace of the reflections. In conclusion, view scans in real-time.
Features & Benefits
- Chafe Location with Inch Accuracy for 200ft Long Coxial Cable
- Low Pulses Safe for Connected Instruments and in Presence of Fuel Vapors
- Greater Sensivity to Cable Impedance Variation than Any…
- 18GHz Track-and-Hold
- >90dB of Dynamic Range
- One-sided Access
| General: | |
| Cable Types | Coxial, Twisted Pair |
| Chafe Detection, Coax | Up to 200 ft. |
| Chafe Detection, Twisted Pair | Up to 20 ft. |
| Electrical: | |
| Input Voltage | 100 to 240 VAC |
| Input Frequency | Input Frequency |
| Mechanical: | |
| Dimensions | 7.1″ x 10.1″ x 8.4″ |
| Weight | 11.5 lbs |
| Pulser: | |
| Pulse Amplitude | 600mV |
| Pulse Width | 3nsec |
| Pulse Repetition Frequency | 20MHz |
| Pulse Rise/Fall Time | 50psec |
| Output Impedance | 50Ω |
| Receiver: | |
| ADC Clock Rate | 10MHz |
| Sampling Rate/Period (Effect) | 50GHz/20psec |
| Full Trace Width | >500nsec (>27K pts) |
| ADC Resolution | 12 bits |
| T&H Analog Bandwidth | 18GHz |
| Averaging, Max | 128,000x |
| Scan Time (Max Averaging) | 3mins |
